Laser tube cutting
dividing tubes with laser
If you’re seeking a more efficient and precise method for cutting pipes and profiles, we offer you 3D laser cutting. The use of precise laser beams for cutting tubes and profiles provides several advantages compared to other material cutting methods. It’s a faster and more accurate process with minimal heat impact on the material being cut, resulting in less waste and fewer errors.
We offer you high-quality cuts with smooth edges, eliminating the need for further processing. Ensuring high dimensional and geometrical accuracy of the finished products is standard.
Our technologies
Cutlite Penta Fiber Tube with bevel head
INTRODUCING NEW TECHNOLOGY
New technology launched in October 2024, a tube laser from Cutline Penta with a power of 4000W and the ability to cut closed, but also open steel and stainless steel profiles. This technology features an automated production system that can produce a finished part with multiple required operations within one working cycle.
The bevel head allows rotation of +/- 45° in both cutting directions.
The maximum dimensions we can process are: circular profiles with a diameter ranging from 20 to 220 mm, or square/rectangular profiles with sides from 20 to 160 mm, and a wall thickness of up to 10 mm
3D Laser-Cutting Capabilities
- Circular tube: Ø 20 mm – 220 mm (at Ø 220 mm allow ±1 % diameter tolerance)
- Square tube: 20 mm × 20 mm up to the square that fits inside a Ø 220 mm circumscribed circle (≈ 155 × 155 mm) At maximum size allow external corner radius = 1.6 – 2.4 × wall thickness (T) and ±1 % side-length tolerance
- Rectangular tube: follows the same rule as square tube (based on Ø 220 mm circumscribed circle) Same corner-radius and ±1 % dimensional tolerance
- Open profiles (I, L, U, H, etc.) Constrained by a Ø 220 mm circumscribed circle. Same corner-radius and ±1 % dimensional tolerance
Maximum cuttable wall thickness by material:
- Carbon / galvanised steel: 1 mm – 15 mm
- Stainless steel: 1 mm – 12 mm
- Aluminium alloys: 1 mm – 12 mm
Additional parameters:
- Bevel-cutting head rotation: 0° – 45° (both directions)
- Maximum raw-material length loaded: 6500 mm
- Maximum finished-part length unloaded: 4000 mm
Accompanying technologies
Threading
For the cut sheet metal parts, we tap threads ranging from M3 to M20. We perform thermal drilling and thread forming ranging from M5 to M10.
Bending of pipes and profiles
Bending of tubes or yak profiles with fully electrically driven technology and high repeat accuracy.
